Cavitation on Zodiac

bdemaso

Recruit
Joined
Aug 2, 2004
Messages
2
Recently purchased a Mark 3 15'5" Zodiac inflatable. Have 25 hp Merc. Had motor on a 11'2" Seaworthy inflatable that would occasionally spin out (cavitate) when in rougher water. Seaworthy had a mimimal keel. Zodiac has a significant keel giving a more v-hull effect. Had the Zodiac on the lake for the first time prior to upcoming ocean trip this weekend and it would cavitate all the time. Could never really get much of a high end speed before it would spin. The transom height is 15" and the front of cavitation plate is level with the bottom with the back of the plate raising 1/2 inch. The former owner had drilled 4 holes in the cav plate and had installed a foil type device that slows the boat speed down for troling. Removed the foil but 4 hole remain? The angle of the motor is the the 2nd hole closest to the transom. Any thoughts or suggestion to my problem?


crazy charlie

Vice Admiral
Joined
May 22, 2003
Messages
5,588
Re: Cavitation on Zodiac

Sounds like you need to change the prop to accomodate for the larger heavier boat.Can you get any weight into the bow to assist you in planing.Did you use the boat with and without the foil.I would guess the foil would help.Charlie


jheron

Petty Officer 1st Class
Joined
Jul 21, 2004
Messages
284
Re: Cavitation on Zodiac

You can try adjusting the angle of the motor I would try and move it closer to the transom thus getting more of the lower unit in the water at plane. I have a 10' zodiac with a 9.8 on it and I tried one of those foils you describe but it would lift the motor rite out of the water and cavitate every time I hit the throttle I had to remove it rite away that was 2 years ago and the holes are still empty and I have no problems.<br />regards Jon


Snowdrggn

Petty Officer 2nd Class
Joined
Sep 16, 2004
Messages
173
Re: Cavitation on Zodiac

I have a 10ft Zodiac with a 15hp Evinrude on it. the OEM prop (9.5x10p) had lots of cavitation/ventilation issues. I switched to a Pirhana prop (10x11p) and it settled down a lot. Also I mounted a set of Smart Tabs on it and they made an incredible difference as far as holeshot and the time it takes to get on a plane (about 1/3). It just kind of gives a little "grunt" and it's up and gone!<br /><br /> http://img.photobucket.com/albums/v48/Snowdrggn/Zodiac/Dscf0051.jpg <br /><br /> http://img.photobucket.com/albums/v48/Snowdrggn/Zodiac/Dscf0052.jpg <br /><br /><br />Just my 2 cents......
