Please help identify this power tilt/trim...

[gunner1]

I need to repair or replace this unit, but it doesn't match up to anything in my manual. Any help would be greatly appreciated. It's on a 1984 ( I believe ) Force 50 hp outboard.



[RRitt]

Re: Please help identify this power tilt/trim...

check johnson/evinrude circa 1970's. don't recall exact model & year but that looks like a johnnyrude to me. i thin it was used on 30-50hp. pick a random year - say 1976 - and look under accessories - electrical - power tilt. you should find one that matches.



[gunner1]

Re: Please help identify this power tilt/trim...

check johnson/evinrude circa 1970's. don't recall exact model & year but that looks like a johnnyrude to me. i thin it was used on 30-50hp. pick a random year - say 1976 - and look under accessories - electrical - power tilt. you should find one that matches.

I checked online at some "johnnyrude" dealers and nothing looked the same.



[gunner1]

Re: Please help identify this power tilt/trim...

I don't know if it'll help, but the piston side said " Prestolite " on it right below the fill plug.



[AOMRESP]

Re: Please help identify this power tilt/trim...

Part #'s Power Trim F5h147 Superceceds To F5h219-1 To 856197a3 To Nla (no Longer Available)

Part #'s Power Tilt F5h143 Superceceds To F5h271 To Nla

Happy Hunting



[RRitt]

Re: Please help identify this power tilt/trim...

it's all NLA? bummer. is that for johnson parts too?

if you get desperate send me a pm. prestolite tends to use the same parts over and over. From pic the motor and ram are standard. The gearcase is unknown. It probably uses standard parts but in a little different configuration to compensate for shape of housing. If you can't find the parts then I can probably fix it in my spare time. if won't be done fast but at least it will be done right. look for parts first though. one-offs suck down tons of time.



[AOMRESP]

Re: Please help identify this power tilt/trim...

JUST CAUSE I'M NICE
PART #856197A3 AVAILABLE AT
10 ALMARS OUTBOARDS INC NEW CASTLE DE 302-328-8541 11/19/2004
1 SHORTS MARINE INC MILLSBORO DE 302-945-1200 03/08/2007

PART #F5H271
Quantity Dealership City State Phone Number Last Updated
10 ALMARS OUTBOARDS INC NEW CASTLE DE 302-328-8541 11/19/2004
2 SHORTS MARINE INC MILLSBORO DE 302-945-1200 03/08/2007
2 FOX LAKE HARBOR FOX LAKE IL 847-587-0200 01/28/2003
1 BILLS MARINE SERVICE OAKLAND MD 301-387-5536 10/17/2004
5 POWERHOUSE MARINE LA CROSSE WI 608-784-9580 12/05/2006

HOPE THIS HELPS
